用 途Usage
汽车维修保养，汽车美容装潢。Auto repair,maintenance,auto decoration.
优 势 Advantage
- 比传统活塞空压机节能30% Energy-saving 30% than
- 操作简单 Easy operating
- 使用寿命长 Longtime lifetime
- 低噪音 Low noise
技术参数 Technical Data
| 型号
Model |
电压
Yoltage (v) |
排气量
Exhaust volume (m²/min) |
压力
Pressure (bar) |
转速 Speed (r/min) | 容积
Volume (L) |
功率
Power (kw) |
重量 Weight (kg) | 外型尺寸 Size
(mm) |
| Z2.2-10-0.3 | 220V 50Hz | 0.3 | 10 | 2900 | 150 | 2.2 | 100 | 1000*400*1000 |
| Z3.0-10-0.4 | 220V 50Hz | 0.4 | 10 | 2900 | 150 | 3 | 105 | 1000*400*1000 |
| Z4.0-10-0.5 | 220V 50Hz | 0.5 | 10 | 2900 | 200 | 4 | 110 | 1100*450*1100 |
| Z5.0-8-0.65 | 220V50Hz | 0.65 | 8 | 2900 | 200 | 5 | 115 | 1100*450*1100 |
| Z4.0-10-0.5 | 380V50Hz | 0.5 | 10 | 2900 | 200 | 4 | 110 | 1100*450*1100 |
| Z5.5-10-0.65 | 380V 50Hz | 0.65 | 10 | 2900 | 200 | 5.5 | 115 | 1100*450*1100 |
| Z7.5-10-1.0 | 380V50Hz | 1.0 | 10 | 2900 | 200 | 7.5 | 120 | 1100*450*1100 |
| Z11-15.5-1.0 | 380V50Hz | 1.0 | 15.5 | 2900 | 300 | 11 | 140 | 1150*500*1150 |
